Work from our shop floor.

A selection of dies, moulds, fixtures, machines and production parts built in house. Customer names are kept confidential.

AllDiesMouldsFixtures & SPMsProduction parts

Progressive die in the press — Progressive dies
Progressive die in the pressFinished progressive die set in the press for tryout.

Progressive die, assembled — Progressive dies
Progressive die, assembledComplete progressive die on the bench with guide posts and strip guides.

Progressive die stations — Progressive dies
Progressive die stationsClose-up of inserts, pilots and strip lifters.

Press die on the hoists — Dies
Press die on the hoistsPainted press die lifted for assembly, guide posts and bushings fitted.

Multi-station punching die — Piercing & punching dies
Multi-station punching dieLong punching die for aluminum profiles, with stations along the full length.

Die rebuild on the bench — Die refurbishment
Die rebuild on the benchLower die opened up for inspection, new details and re-timing.

Blow mould spotting — Moulds
Blow mould spottingLarge blow mould cavity spotted, parting line taped for tryout.

Multi-cavity injection mould — Moulds
Multi-cavity injection mouldMould half with runner system and water lines, on the mould stand.

Blow mould half — Moulds
Blow mould halfRibbed bottle cavity with cooling fittings.

Spoiler mould cavity — Moulds
Spoiler mould cavityPolished Class A spoiler cavity, machined and finished in house.

Cross car duct trim nest — Trim nests
Cross car duct trim nestP20 trim nest machined and fitted to the duct part.

Long 4th-axis fixtures — Fixtures
Long 4th-axis fixturesPair of 74-inch 4th-axis machining fixtures on stands.

5-axis fixture — Fixtures
5-axis fixtureFixture tilted on the 5-axis trunnion for multi-side machining.

4-axis tombstone fixture — Fixtures
4-axis tombstone fixtureMulti-station tombstone for high-volume 4-axis machining.

Special purpose machine — SPMs
Special purpose machineMulti-station cell with pneumatic presses, guarded and ready to ship.

Machined weldments — Weldments
Machined weldmentsWelded and machined fabrications ready for shipment.

3-axis contour cutting — 3-axis CNC
3-axis contour cuttingContoured form cut on a large welded fixture base.

Contoured fixture, machined — 3-axis CNC
Contoured fixture, machinedLarge welded fixture with 3D contours machined in one setup.

Contoured cavity — 5-axis CNC
Contoured cavityFlowing 3D cavity surfaces in steel.

5-axis fixture setup — 5-axis CNC
5-axis fixture setupAngle-plate fixture holding a row of parts on the 5-axis machine.

Turned ring inspection — CNC turning
Turned ring inspectionPrecision-turned ring checked on the granite plate.

Machined parts batch — Batch production
Machined parts batchPrecision parts machined, inspected and packed.

Aluminum extrusion batch — Batch production
Aluminum extrusion batchPierced and machined aluminum extrusions, stacked for delivery.

Brass contour parts — Batch production
Brass contour partsRepeat batch of contoured brass components.
